ID # 19810672

New Holland TS6 SERIES II

Call for Price
Overview

ANYTHING BUT BASIC

TS6 tractors are Standard tractors are rugged, comfortable and flexible. The fact they are affordable is an added bonus.

MORE POWER AND TORQUE

Tier 4B engines provide more horsepower and torque than previous models while reducing emissions and fuel use.

REWARD YOURSELF WITH COMFORT

Both the VisionsView™ cab and open, flat-deck platform give you plenty of room and operating ease.

HIGH-CLEARANCE MODEL AVAILABLE

The TS6.120 High-Clearance tractor nimbly maneuvers down rows of vegetable and specialty crops.

POWER THAT’S EFFICIENT, COMFORTABLE AND AFFORDABLE.

NEW TS6 Series II tractors are the new face of standard tractors, yet these tractors are anything but basic. They’re big on power and efficiency, loaded with comfort, and ready to handle your toughest tasks. In short, they’re your best choice if you’re looking for a strong, modern and affordable all-purpose tractor.New Holland TS6 SERIES II

YOUR CHOICE OF CAB, ROPS, 2WD, 4WD

Four TS6 models range from 90 to 115 PTO horsepower and fit a wide range of farming practices. Choose a model with two- or four-wheel drive, with an open ROPS platform or New Holland’s VisionView™ cab. For vegetable and specialty crops, look to the TS6.120 High-Clearance model.

New Holland TS6 SERIES II

AVAILABLE IN A PLUS OR VALUE PACKAGE

You can pick and choose your options if you like, or choose from two preferred customer packages.
TS6 VALUE tractors feature an 8x8 transmission with power shuttle and a 19-mph transport speed, with 13-gpm implement hydraulics and 3,735-pound three-point lift capacity.
TS6 PLUS models feature higher specifications and more deluxe features to increase comfort and productivity. PLUS models offer increased 22-gpm hydraulic capacity and 5,499-pound hitch lift capacity, and double the forward speeds and a faster 25-mph travel speed with a 16x8 transmission. The PLUS cab also features added comfort and convenience with an air suspension seat with swivel, plus instructor seat, rear wiper/washer, radio, and an overhead high-visibility panel.New Holland TS6 SERIES II


COMPLETE LOADER READY OPTION

You can order both TS6 Plus and Value tractors with complete factory installation of everything needed for a matching New Holland front loader. The loader ready option includes the loader joystick, two-function mid-mount valve with hoses and couplers to attach to the loader hydraulics, TPS mounts and grill guard.
New Holland TS6 SERIES II
Specifications
Model
TS6 SERIES II
Year
2022
Sale Type
New
Manufacturer
New Holland
Engine*
4 cylinder, 16 valve, high pressure common rail, air-to-air intercooled turbo diesel
Fuel Tank Capacity Gal. (l)
57.5 (217.6)
engine
New Holland TS6 SERIES II

A HUGE LEAP IN PERFORMANCE AND EFFICIENCY

TS6 Series II engines are Tier 4B emissions certified, and deliver power and performance without compromise. The common rail fuel injection system provides precise metering of fuel injection which reduces engine noise, has better fuel combustion, higher horsepower per cylinder, lower emissions and enhanced fuel economy.

New Holland TS6 SERIES II

MORE POWER AND TORQUE THAN PREVIOUS TS6 MODELS

TS6 four-cylinder engines use the latest New Holland engine technology to maximize the power delivered per cylinder, resulting in performance that’s significantly better than the Tier 3 engine used on previous TS6 models. With four valves per cylinder, and the electronically controlled common rail fuel system, these engines generate more torque, more quickly and hold it longer for better lugging ability. You get better throttle response and a noticeable increase in loaded engine performance in difficult crop or soil conditions.

ECOBLUE™ HI-ESCR TECHNOLOGY—ONE SIMPLE SOLUTION

New Holland’s ECOBlue HI-eSCR after-treatment system is a simple solution that not only reduces emissions, but also improves fuel efficiency so you complete more work with less fuel.

New Holland TS6 SERIES II

CLEANER AIR WITH DUST EJECTOR

The engine gets cleaner air thanks to a new radiator fan shroud that creates a vacuum that pulls debris from the air filter.

New Holland TS6 SERIES II

ADDED VENTILATION

Slanted rear-side louvers provide additional ventilation for the Diesel Oxidation Catalyst (DOC).



transmission

PROVEN CHOICES TO MATCH YOUR NEEDS

TS6 Series II tractors offer a selection of reliable transmissions, including a choice of a 19-mph or 25-mph road speed (4WD only) and choice of mechanical or power (forward/reverse) shuttle.

New Holland TS6 SERIES II

POWER SHUTTLE

The easy-to-use, left-hand power shuttle provides fast, smooth direction changes and is ideal for loader work.New Holland TS6 SERIES II

25-MPH (40-KPH) ROAD SPEED

Choose the faster 25-mph road speed (4WD only) for faster field-to-field travel and to shorten long transport trips.New Holland TS6 SERIES II

10:1 CREEPER

For slow speed applications, an optional 10:1 Creeper is available on all transmission to provide speeds as slow as 0.136 mph. You engage it electro-hydraulically using a switch on the Command Arc™ console.



hydraulics and 3-point hitch

TOTAL FLOW UP TO 29 GPM

TS6 Series II tractors have the hydraulic flow to handle demanding implements. Both Value and Plus models feature a 13-gallon-per-minute (gpm) implement pump and a dedicated 7-gpm steering pump. A 9-gpm auxiliary pump is standard on Plus models and optional on Value models, for a total flow of 29 gpm. Implement hydraulic oil flow will be less than pump flow measured at the remote couplers.

New Holland TS6 SERIES II

REAR REMOTES

Rear hydraulic remote valves are controlled by the ergonomically placed levers on the CommandArc™ control console. Two deluxe closed center hydraulic remote valves with couplers are standard equipment, with an optional third and fourth valve.New Holland TS6 SERIES II

UP TO 7,326 POUNDS OF LIFT

You can handle heavy three-point-mounted implements with ease. The standard 3,735-pound lift capacity is a great match for most implements. Increase it to 5,499 pounds by adding one optional auxiliary lift cylinder, or add two lift cylinders to increase to 7,326-pound lift capacity. No matter how heavy the implement, the standard telescoping stabilizers and flexible link ends provide easy hook up to any 3-point hitch tool. An external ground control of the three-point hitch is included with the Plus package.

New Holland TS6 SERIES II



models and specification
New Holland TS6 SERIES II TS6.110
Engine Type 4 cylinder, 16 valve, high pressure common rail, air-to-air intercooled turbo diesel
Rated engine horsepower @ 2200 RPM
9 ft., 2 in.
110
Base transmission 8x8 synchronized hydraulic shuttle with left hand shuttle
PTO rpm 540/1000
New Holland TS6 SERIES II TS6.120
Engine Type 4 cylinder, 16 valve, high pressure common rail, air-to-air intercooled turbo diesel
Rated engine horsepower @ 2200 RPM
9 ft., 2 in.
119
Base transmission 8x8 synchronized hydraulic shuttle with left hand shuttle
PTO rpm 540/1000
New Holland TS6 SERIES II TS6.120 High Clearance
Engine Type     4 cylinder, 16 valve, high pressure common rail, air-to-air intercooled turbo diesel
Rated engine horsepower @ 2200 RPM
9 ft., 2 in.
119
Base transmission 8x8 synchronized hydraulic shuttle with left hand shuttle
PTO rpm 540/1000
New Holland TS6 SERIES II TS6.130
Engine Type 4 cylinder, 16 valve, high pressure common rail, air-to-air intercooled turbo diesel
Rated engine horsepower @ 2200 RPM
9 ft., 2 in.
130
Base transmission 8x8 synchronized hydraulic shuttle with left hand shuttle
PTO rpm 540/1000
New Holland TS6 SERIES II TS6.140
Engine Type 4 cylinder, 16 valve, high pressure common rail, air-to-air intercooled turbo diesel
Rated engine horsepower @ 2200 RPM
9 ft., 2 in.
139
Base transmission 8x8 synchronized hydraulic shuttle with left hand shuttle
PTO rpm 540/1000
